Location：Home > Product Center > Industrial Lighting > Transparent Panel Light Series
Excellent nano-particles light guide plate to assure soft light and high light-outing efficiency.
High CRI, high luminous efficiency to assure the best and clearest color, also with dimmable CCT.
A novel and fashion design integrated with humanization and technology.
With master lighting in the middle of light, and brightness dimmable is available both for master lighting and normal lighting.
EUcertification No 005155017-0001.
High quality light source, The light uniformity is up to 90%.
MITSUBISHI laser point.
Chips: Bridge lux.
| Non Dimmable | CCT Dimmable | Brightness Dimmable | |
|---|---|---|---|
| Model | BM-TPL24040 | BM-TPL24040 | BM-TPL24040 |
| Voltage | AC 200~240 V | AC 100-240V | AC100-240V |
| CRI | ≥80 | ≥80 | ≥80 |
| Lm/W | 100 | 80 | 100 |
| Watt(W) | 40 | 40 | 40 |
| Lumen(lm) | 4000 | 3200 | 4000 |
| PF | >0.9 | >0.9 | >0.9 |
| CCT | 3000K-4000K-6500K | 3000K~6500K | 3000K-4000K-6500K |
| Beam Angle | 140° | 140° | 140° |
| Warranty | 3/5 years | 3/5 years | 3/5 years |
